Power Supply Input Voltage AC200V ±20%, DC110V / 220V
Maximum Power Consumption ≤3W
Wireless Operating Bandwidth 433MHz (Zigbee)
Wireless Reception Sensitivity -110dBm
Wireless Receiving Distance 0.4 ~ 200meter
Communication Output RS485
RS 485 Communication Distance <1200m
Alarm of outputs Relay output
Output relay AC220V, 3A
Communication Rate 2400 ~ 9600 bps (Default 2400bps)
Communication Protocol Standard Modbus-RTU protocol
Max number of sensors 18 pcs
Display Screen
Graphic Display Screen LCD Type LCD display (FSTN)
Viewing area 3.5 inch
Illumination backlight White LED
Resolution Ratio 160 x 160
Miscellaneous
Dimensions Size 105 x 96 x 96 (mm)
Mounting cut-out 86.5 x 86.5 (mm)
Weight 0.40 (kgs)
Operation Temperature -20⁰C ~ 70⁰C
Relative Humidity (RH) ≤95%RH (non-condensing)
Storage Temperature -20⁰C ~ 70⁰C
Mounting method Embedded
